2 " serial prismless 600m Total Station Instrument Survey And Construction IP54

Ask Lasest Price
Brand Name :	GEOALLEN
Model Number :	GTS342R6A
Price :	USD
Payment Terms :	L/C, T/T
Supply Ability :	10000pcs
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

2 " serial prismless 600m Total Station Instrument Survey And Construction IP54

GTS 342R6A 2" serial prismless 600m total station for survey and construction

Specifications

		GTS-342R6A
DISTANCE MEASURING
Max. Distance	one prism	3.5KM
(good weather)	reflecting paper	1KMm (based on different condition)
	prismless	600m (based on different condition)
display		Max:999999.99M Min:1MM
accuracy		2+2PPM(with prism), ＜100M,3+2PPM,＞100M,5+5PPM(no prism, fine)
measuring time		fine: ＜1.5s, tracing: 0.1s,repeat:＜0.3s
wether constance change		automatic change after input constance
prism constance change		automatic change after input constance
ANGLE MEASURING
measurment way		absolute encode
Crosshair plate diam.		79MM
Min. Reading		1" optional
accuracy		2"
VERTICAL COMPENSATOR
system		dual axis liquid-electric sensor
working range		+/-4'
precision		1"
LEVEL SENSITIVITY
plate level		30"/2mm
cicular level		8'/2mm
TELESCOPE
image		erect
length of telescope		152MM
Diam. of objective len's		telescope:45mm/distance measure:47mm
Magnificant		30*
Field of view		1° 30'
Min. focus		1.3m
DISPLAY
type		dual face
POWER
source		chargeable lithium battery
voltage		DC7.4V
continues working time		8 H
MEASURMENT AND WEIGHT
dim.		L216W200H350 MM
weight		6.0KG

2 " serial prismless 600m Total Station Instrument Survey And Construction IP54

600m reflectorless measurement Laser pointer, Data transfer and storage Flash disk
easy to find target and SD card, Mini USB

Bluetooth transportation Concentrated ball bearing
BT 4.0, easy connect to data collector, etc Solve axis jam, more stable and reliable

T-P sensor, automatic correction Totally new design for battery

EDM Trigger Key
Quick Measure Key locates on the side cover, which avoids any possible torque during the angle measurement.
